Interceptors in gRPC-Web

June 18, 2020


Zhenli Jiang, Google

We’re pleased to announce support for interceptors in gRPC-web as of release 1.1.0. While the current design is based on gRPC client interceptors available from other gRPC languages, it also includes gRPC-web specific features that should make interceptors easy to adopt and use alongside modern web frameworks.

Introduction

Similar to other gRPC languages, gRPC-web supports unary and server-streaming interceptors. For each kind of interceptor, we’ve defined an interface containing a single intercept() method:

  • UnaryInterceptor
  • StreamInterceptor

This is how the UnaryInterceptor interface is declared:

/*
* @interface
*/
const UnaryInterceptor = function() {};

/**
 * @template REQUEST, RESPONSE
 * @param {!Request<REQUEST, RESPONSE>} request
 * @param {function(!Request<REQUEST,RESPONSE>):!Promise<!UnaryResponse<RESPONSE>>}
 *     invoker
 * @return {!Promise<!UnaryResponse<RESPONSE>>}
 */
UnaryInterceptor.prototype.intercept = function(request, invoker) {};

The intercept() method takes two parameters:

  • A request of type grpc.web.Request
  • An invoker, which performs the actual RPC when invoked

The StreamInterceptor interface declaration is similar, except that the invoker return type is ClientReadableStream instead of Promise. For implementation details, see interceptor.js.

Note

A StreamInterceptor can be applied to any RPC with a ClientReadableStream return type, whether it’s a unary or a server-streaming RPC.

What can I do with an interceptor?

An interceptor allows you to do the following:

  • Update the original gRPC request before passing it along — for example, you might inject extra information such as auth headers
  • Manipulate the behavior of the original invoker function, such as bypassing the call so that you can use a cached result instead
  • Update the response before it’s returned to the client

You’ll see some examples next.

Unary interceptor example

The code given below illustrates a unary interceptor that does the following:

  • It prepends a string to the gRPC request message before the RPC.
  • It prepends a string to the gRPC response message after it’s received.

This simple unary interceptor is defined as a class that implements the UnaryInterceptor interface:

/**
 * @constructor
 * @implements {UnaryInterceptor}
 */
const SimpleUnaryInterceptor = function() {};

/** @override */
SimpleUnaryInterceptor.prototype.intercept = function(request, invoker) {
  // Update the request message before the RPC.
  const reqMsg = request.getRequestMessage();
  reqMsg.setMessage('[Intercept request]' + reqMsg.getMessage());

  // After the RPC returns successfully, update the response.
  return invoker(request).then((response) => {
    // You can also do something with response metadata here.
    console.log(response.getMetadata());

    // Update the response message.
    const responseMsg = response.getResponseMessage();
    responseMsg.setMessage('[Intercept response]' + responseMsg.getMessage());

    return response;
  });
};

Stream interceptor example

More care is needed to intercept server-streamed responses from a ClientReadableStream using a StreamInterceptor. These are the main steps to follow:

  1. Create a ClientReadableStream-wrapper class, and use it to intercept stream events such as the reception of server responses.
  2. Create a class that implements StreamInterceptor and that uses the stream wrapper.

The following sample stream-wrapper class intercepts responses and prepends a string to response messages:

/**
 * A ClientReadableStream wrapper.
 *
 * @template RESPONSE
 * @implements {ClientReadableStream}
 * @constructor
 * @param {!ClientReadableStream<RESPONSE>} stream
 */
const InterceptedStream = function(stream) {
  this.stream = stream;
};

/** @override */
InterceptedStream.prototype.on = function(eventType, callback) {
  if (eventType == 'data') {
    const newCallback = (response) => {
      // Update the response message.
      const msg = response.getMessage();
      response.setMessage('[Intercept response]' + msg);
      // Pass along the updated response.
      callback(response);
    };
    // Register the new callback.
    this.stream.on(eventType, newCallback);
  } else {
    // You can also override 'status', 'end', and 'error' eventTypes.
    this.stream.on(eventType, callback);
  }
  return this;
};

/** @override */
InterceptedStream.prototype.cancel = function() {
  this.stream.cancel();
  return this;
};

The intercept() method of the sample interceptor returns a wrapped stream:

/**
 * @constructor
 * @implements {StreamInterceptor}
 */
const TestStreamInterceptor = function() {};

/** @override */
TestStreamInterceptor.prototype.intercept = function(request, invoker) {
  return new InterceptedStream(invoker(request));
};

Binding interceptors

By passing an array of interceptor instances using an appropriate option key, you can bind interceptors to a client when the client is instantiated:

const promiseClient = new MyServicePromiseClient(
    host, creds, {'unaryInterceptors': [interceptor1, interceptor2, interceptor3]});

const client = new MyServiceClient(
    host, creds, {'streamInterceptors': [interceptor1, interceptor2, interceptor3]});

Note

Interceptors are executed in reverse order for request processing, and in order for response processing, as illustrated here:

Interceptor processing order

Feedback

Found a problem with grpc-web or need a feature? File an issue over the grpc-web repository. If you have general questions or comments, then consider posting to the gRPC mailing list or sending us an email at grpc-web-team@google.com.
